Price: $19.25 - $17.09
(as of Aug 02,2023 18:58:42 UTC – Details)
How to Use:
It is installed on the right pedal, and the waterproof interface can be connected to the controller.
Specification:
Item Type: Electric Bicycle Assist Sensor
Material: PC Plastic
Hall Electrical Life: >20M times
Rated Voltage: 4.5-6V (DC)
No Braking Current: <5mA
With Braking Current: <6mA
Insulation Dry Condition: > 20M ohm
Insulation Wet Conditions: > 2M ohm
Braking Corresponding Time: <0.001S
Corresponding Distance: 2-3mm
Package List:
1 x Sensor Wiring
1 x Sensor Sheet
[12 Magnets]- With 12 magnets, the accuracy will be higher than with 5 magnets, and the distance from the sensor will be longer. In terms of sensitivity, it is 2‑3 times that of ordinary 5 magnets, and there is no wrong action.
[Pulse Signal]- Installed on the right side of the pedal by default, with 12 pulses in a circle. The chip screens and identifies the pulse signal to determine the rotation direction. The forward direction is valid, and the reverse direction is invalid.
[LED]- When the pedal moves forward, the sensor will output a pulse signal, and the LED is at a low level (with or without a pulse signal), so the LED will not flash.
[Dual Hall Sensors]- The electric bicycle assist sensor housing has dual Hall sensors to detect the riding of the bicycle.
